Ubiquiti airMAX Antenna AM-5G19-120
The Ubiquiti AirMax 5 GHz (AM-5G19-120) achieves gain, cross-pol isolation, and beamshaping characteristics that rival the highest quality cellular carrier basestation antennas in the world. Instantly pair the Ubiquiti AirMax 5 GHz with Rocket M5 to create a powerful AirMax 2×2 MIMO PtMP BaseStation.
Ubiquiti airMax 5 GHz Key Features
○ 5GHz 19dBi High Performance
○ Long Range (120 degrees)
○ Seamlessly Integrates with Rocket M5 APs
○ Excellent Cross-Polarisation Isolation
○ Intelligent QoS – Priority is given to voice/video for seamless streaming
○ High Capacity and Scalability
Breakthrough Design and Performance
The innovative airMAX Sector Antenna features carrier-class construction and 2×2, dual-polarity performance.
Reduced Interference, Higher Gain
Highly resistant to noise interference, the airMAX Sector Antennas provide superior gain and beam performance for high-capacity,
Industrial-Strength Construction
airMAX Antennas are designed with robust mechanical design for outdoor application use.
| AM-5G19-120 Specification | |
|---|---|
| Model | AM-5G19-120 |
| Dimensions | 700 x 135 x 73 |
| Weight | 5.9 kg |
| Frequency Range | 5.15 – 5.85 GHz |
| Gain | 18.6 – 19.1 dBi |
| HPOL Beamwidth | 123° (6 dB) |
| HPOL Beamwidth | 123° (6 dB) |
| Electrical Beamwidth | 4° |
| Wind Survivability | 125mph |
| Wind Loading | 20 lbf @ 100 mph |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 28 dB Min. |
| Cross-pol Isolation | Universal Pole Mount, Rocket M Bracket, and Weatherproof RF |
airMAX Sector Antenna Datasheet
Please visit the Ubiquiti Firmware page for the latest Firmware upgrades
