Ubiquiti LTU Long Range (LTU-LR)

Ubiquiti LTU Long Range 5 GHz PtMP LTU Client Radio LTU-LR

The Ubiquiti LTU Long Range is a long range, 5 GHz subscriber station that functions as a CPE (Customer Premises Equipment) in a Point-to-MultiPoint (PtMP) environment with the LTU Rocket as the Basestation. It features an integrated high-gain antenna for long range and high performance. Channel width flexibility (10/20/30/40/50 MHz) allows independent TX and RX channel frequency configurations anywhere within the radio band to avoid local interference.

Ubiquiti LTU-LR Key Features
○ Proprietary Ubiquiti LTU Processor
○ Long-Range 26 dBi Antenna with High-Power InnerFeed
○ PtMP CPE
○ 1024 QAM
○ 10/20/30/40/50 MHz channel bandwidth
○ Central configuration management from AP side
○ Frequency split
○ Auto power adjustments
○ Router mode support
○ Range up to 30km

Proprietary LTU Technology
Based on Ubiquiti’s LTU technology, the LTU LR is not impeded by the limitations of standard 802.11 Wi-Fi technology. Its custom LTU silicon and radio architecture provide up to 600+ Mbps1 of real TCP/IP throughput and modulation rates of up to 4096QAM2.

CPE Modes
The LTU Lite LR both bridged and built-in hardware NAT router modes to suit your specific deployment.

Frequency Split
The LTU LR can use different frequencies for TX and RX to avoid interference.

Improved Noise Immunity
The LTU LR directs RF energy in a tighter beamwidth. With the focus in one direction, the LTU LR blocks or spatially filters out noise to improve noise immunity. This is especially important in an area crowded with other RF signals of the same or similar frequency.

Innovative Design
Ubiquiti’s InnerFeed technology integrates the radio into the feedhorn of a 26 dBi antenna, so there is no need for a cable. This improves performance because it eliminates cable losses.

Quick Mounting and Alignment
The LTU LR features a large reflector size and easy elevation adjustment (azimuth is adjusted by rotation around the pole).
