Ubiquiti LBE 5AC LR. The Long Range Radio CPE
Designed for long-range applications, the Ubiquiti airMAX LiteBeam 5AC LR features a larger reflector size and elevation adjustment (azimuth is adjusted by rotation around the pole).
Ubiquiti Networks launches the latest generation of airMAX CPE (Customer Premises Equipment), the LiteBeam 5AC Gen 2, with dedicated Wi-Fi management. Improved Noise Immunity The LiteBeam 5AC Gen 2 directs RF energy in a tighter beamwidth. With the focus in one direction, the LiteBeam 5AC Gen 2 blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency. The LiteBeam 5AC Gen 2 offers quick and easy alignment and enhanced protection against power surges.
Specifications of LBE 5AC LR
• Dimensions: 512.5 x 385.75 x 258.3 mm (20.18 x 15.19 x 10.17″)
• Weight
&nbps; Without Mount: 1.360 kg (2.998 lb)
&nbps; With Mount: 1.735 kg (3.825 lb)
• Power Supply: 24V, 0.3A Gigabit PoE Adapter (Included)
• Max. Power Consumption: 7W
• Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
• Supported Voltage Range: 24V ± 10%
• Gain 26 dBi
• Networking Interface (1) 10/100/1000 Ethernet Port
• Processor Specs MIPS 74Kc
• Memory 64 MB DDR2
• LEDs Power, Ethernet
• Channel Sizes: &nbps; &nbps; PtP Mode: 10/20/30/40/50/60/80 MHz
&nbps; &nbps; &nbps; &nbps; PtMP Mode: 10/20/30/40 MHz
• Enclosure Characteristics Reflector (Aluminum) / Plastic: PC
• Mounting Pole-Mounting Kit (Included)
• Wind Loading 550 N @ 200 km/h (123.6 lbf @ 125 mph)
• Wind Survivability 200 km/h (125 mph)
• ESD/EMP Protection ± 24 kV Contact / Air
• Operating Temperature -40 to 70° C (-40 to 158° F)
• Operating Humidity 5 to 95% Non-condensing
• Certifications CE, FCC, IC
Product Includes
(1) LiteBeam 5AC Long Range CPE LBE 5AC LR
(1) Gigabit PoE Adapter (24V 0.3A)
(1) Mounting Bracket
(1) User Manual
