Ubiquiti airMAX NanoStation AC Loco NS-5ACL

The Ubiquiti NanoStation AC Loco (NS-5ACL) gets maximum gain out of the smallest footprint. The low cost, high-performance, and small form factor of the NS-5ACL makes it extremely versatile and economical to deploy.

Sleek Industrial Design
The NanoStation AC Loco (NS-5ACL) represents the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.

Ubiquiti NanoStation AC Loco (NS-5ACL) – Technical Specifications

• Dimensions: 179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33″)
• Weight: 180 g (6.35 oz)
• Power Supply: 24V, 0.5A Gigabit PoE Supply*
• Max. Power Consumption: 8.5W
• Power Method: Passive PoE (Pairs 4, 5+; 7, 8 Return)
• Gain: 13 dBi
• Networking Interface: 10/100/1000 Mbps Ethernet Port
• Channel Bandwidths: 10/20/30/40/50/60/80 MHz
• Processor Specs: Atheros MIPS 74Kc, 560 MHz
• Memory: 64 MB DDR2
• Cross-pol Isolation:
• 20 dB Minimum
• Max. VSWR 1.8:1
• Beamwidth: 45 degrees (H-pol) / 45 degrees (V-pol) / 45 degrees (Elevation)
• Polarization: Dual Linear
• Enclosure: Outdoor UV Stabilized Plastic
• LEDs: (1) Power
• Mounting: Pole-Mount (Kit Included)
• Operating Temperature: -40 to 70 C (-40 to 158 F)
• Operating Humidity: 5 to 95% Noncondensing
• RoHS Compliance: Yes
• ESD/EMP Protection: ±24kV Contact/Air
• Shock & Vibration: ETSI300-019-1.4
• Certifications: CE, FCC, IC
• Operating Frequency (MHz): 5150 – 5875
• Management Radio (MHz): 2412 – 2472
